WebView2 by sklein - Toolkit for LabVIEW Download
Provides wrapping class for WebView2, the .net widget providing an edge compatible browser
Discussion
| Version | 2.1.0.34 |
| Released | Jan 04, 2026 |
| Publisher | sklein |
| License | BSD-3 |
| LabVIEW Version | LabVIEW>=20.0 |
| Operating System | Windows |
| Used By | illuminatedg_lib_summer_of_labview___formulag shireystudios_lib_via_plus sklein_lib_webview2_qcontrol nevstop_lib_csm_mermaid_plugin illuminatedg_lib_ig_godotserver sklein_lib_webview2_xcontrol |
| Project links | Homepage Documentation Repository Discussion |
Description
This package provides wrappers around the WebView2 .NET Control.
The needed library from nuget is included. Please see the LICENSE.txt for lincensing information regarding the webview2 nuget package.
The wrapper exposes a few useful events, methods and properties. It comes in three flavors:
* A LabVIEW class which manages a wrapper around a webview2 instance (This package, preferred)
* A QControl for advanced usage (package WebView2 QControl)
* A XControl which exposes the wrapper as a ready to use control (package WebView2 XControl).
Features:
- Drop in browser control
- customizable paths and environment options
- Javascript execution with result
- WebMessage sending and reception through events
- Content by URI or raw HTML
- Status Events
- PDF printing
- Update wizard for webview2 assemblies from nuget (Tools->WebView2)
Release Notes
- Added updater to tools menu / post install
